Specifications

• Engine

  add remove
  • Engine Type:
    Single-Cylinder
  • Engine:
    Standard
  • Cylinders:
    1
  • Engine Stroke:
    4-Stroke
  • Cooling:
    Air
  • Valves:
    2
  • Valves Per Cylinder:
    2
  • Valve Configuration:
    OHV
  • Bore (mm):
    78.5
  • Bore (in):
    3.09
  • Stroke (mm):
    68
  • Stroke (in):
    2.68
  • Displacement (cc):
    329
  • Displacement (ci):
    20.1
  • Fuel Type:
    Gas
  • Fuel Requirements:
    Regular
  • Carburetion:
    Standard
  • Fuel Injector:
    No
  • Carburetor:
    Yes
  • Number Of Carburetors:
    1
  • Carburetor Size (mm):
    32
  • Carburetion Type:
    Carburetor
  • Parental Controls:
    Not Available
  • Kill Switch / Tether Cord:
    Not Available
  • Snorkel Air Intake:
    Standard
  • Engine Block Heater:
    Not Available
  • Compression Ratio:
    8.7:1
  • Starter:
    Electric / Pull
• PRICING

  add remove
  • Price:
    Standard
  • MSRP:
    5099
  • MSRP + Destination:
    5099
  • Currency:
    US Dollars
  • Warranty (Months):
    6
• TRANSMISSION

  add remove
  • Transmission:
    Standard
  • Transmission Type:
    Manual / Automatic Clutch
  • Number Of Speeds:
    5
  • Primary Drive (Rear Wheel):
    Shaft
  • Reverse:
    Yes
  • Adjustable Throttle:
    Not Available
  • Primary Drive (Front Wheel):
    Shaft
• DRIVE LINE

  add remove
  • Driveline:
    Standard
  • Driveline Type:
    4X4
  • Number Of Driveline Modes:
    1
  • Rear Unlocking Differential:
    No
  • Limited Slip Differential:
    Standard
  • Differential Lock:
    Not Available
  • Limited Slip Differential Location:
    Front
• TECHNICAL SPECIFICATIONS

  add remove
  • Dimensions:
    Standard
  • Length (mm):
    1983.7
  • Width (in):
    45
  • Width (mm):
    1143
  • Height (in):
    44.3
  • Height (mm):
    1125.2
  • Wheelbase (in):
    49.1
  • Wheelbase (mm):
    1247.1
  • Turning Radius (ft):
    10.8
  • Ground Clearance (in):
    7.2
  • Ground Clearance (mm):
    182.9
  • Weight:
    Standard
  • Dry Weight (lbs):
    535
  • Dry Weight (kg):
    242.7
  • Capacities:
    Standard
  • Fuel Capacity (gal):
    3.4
  • Fuel Capacity (l):
    12.9
  • Fuel Capacity Reserve (gal):
    0.8
  • Fuel Capacity Reserve (l):
    3
  • Performance:
    Standard
  • Engine Displacement to Weight (cc):
    0.61
  • Towing Capacity (lbs):
    850
  • Towing Capacity (kgs):
    385.6
  • GVWR (lbs):
    1045
  • GVWR (kgs):
    474
• SUSPENSION

  add remove
  • Front Suspension:
    Standard
  • Front Suspension Type:
    Independent Double Wishbone
  • Front Travel (in):
    5.9
  • Front Travel (mm):
    149.9
  • Front Adjustable Fork Pre-Load:
    No
  • Front Adjustable Rebound Damping:
    No
  • Front Central Suspension Strut:
    No
  • Front Stabilizer Bar:
    No
  • Steering Damper:
    No
  • Rear Suspension:
    Standard
  • Rear Suspension Type:
    Swing Arm
  • Rear Suspension Material:
    Steel
  • Rear Travel (in):
    5.9
  • Rear Travel (mm):
    149.9
  • Rear Adjustable Shock / Spring Pre-Load:
    No
  • Rear Adjustable Rebound Damping:
    No
  • Number Rear Shock Absorbers:
    1
  • Rear Stabilizer Bar:
    No
  • Air Adjustable:
    No
• WHEELS & TIRES

  add remove
  • Wheels:
    Standard
  • Wheels Composition:
    Steel
  • Chromed:
    No
  • Front Tire Diameter (in):
    24
  • Rear Tire Diameter (in):
    24
  • Tires:
    Standard
  • Tire Brand:
    Bridgestone®
  • Front Tire Width:
    8
  • Front Wheel Diameter:
    12
  • Rear Tire Width:
    9
  • Rear Wheel Diameter:
    11
  • Front Tire (Full Spec):
    Bridgestone® 24 X 8-12
  • Rear Tire (Full Spec):
    Bridgestone® 24 X 9-11
  • Tire Chains:
    Not Available
  • Spare Tire:
    Not Available
  • Tube / Tubeless:
    Tubed
• BRAKES

  add remove
  • Brakes:
    Standard
  • Front Brake Type:
    Sealed Hydraulic Drum
  • Rear Brake Type:
    Sealed Drum
  • Anti-Lock Brakes:
    Not Available
  • Parking Brake:
    Standard
  • Linked Brake System Front to Rear:
    Not Available
  • Engine Braking:
    Not Available
  • Regenerative Braking:
    Not Available
  • Regenerative Deceleration:
    Not Available
• TOWING & HAULING

  add remove
  • Front Hitch:
    Not Available
  • Rear Hitch:
    Standard
  • Draw Bar:
    Not Available
  • Tow Hook:
    Not Available
  • Trailer:
    Not Available
  • Winch:
    Not Available
  • Roller Fairlead:
    Not Available
• SEATS

  add remove
  • Seat:
    Standard
  • Seat Type:
    One-Piece
  • Seat Location:
    Driver
  • Seat Material:
    Vinyl
  • Seat Specifications:
    Standard
  • Seat Height (in):
    32.4
  • Seat Height (mm):
    823
  • Number Of Seats:
    1
  • Detachable Passenger Seat:
    Not Available
  • Seat Backrest:
    Not Available
  • Grab Rail or Strap:
    Not Available
  • Heated Seat:
    Not Available
