Specifications

• ENGINE

  add remove
  • Engine Type:
    Single-Cylinder
  • Cylinders:
    1
  • Engine Stroke:
    4-Stroke
  • Horsepower (bhp):
    7
  • Valves:
    4
  • Valves Per Cylinder:
    4
  • Valve Configuration:
    DOHC
  • Bore (in):
    1.57
  • Stroke (in):
    1.56
  • Displacement (cc):
    49
  • Carburetion Type:
    Carburetor
  • Number Of Carburetors:
    1
  • Compression Ratio:
    11.7:1
• TRANSMISSION

  add remove
  • Transmission Type:
    Manual
  • Number Of Speeds:
    6
  • Primary Drive (Rear Wheel):
    Chain
  • Reverse:
    No
• TECHNICAL SPECIFICATIONS

  add remove
  • Wheelbase (in):
    47
  • Dry Weight (lbs):
    156.5
  • Fuel Capacity (gal):
    1.6
  • Engine Displacement to Weight (cc):
    0.31
  • Length (in):
    70.5
  • Width (in):
    24.2
  • Height (in):
    37.2
• SUSPENSION

  add remove
  • Front Suspension Type:
    Telescopic Fork
  • Front Adjustable Fork Pre-Load:
    No
  • Front Adjustable Rebound Damping:
    No
  • Front Central Suspension Strut:
    No
  • Rear Suspension Type:
    Twin Sided Swing Arm
  • Rear Adjustable Shock / Spring Pre-Load:
    No
  • Rear Adjustable Rebound Damping:
    No
  • Number Rear Shock Absorbers:
    2
• WHEELS & TIRES

  add remove
  • Front Tire (Full Spec):
    90/100 R18
  • Rear Tire (Full Spec):
    2.5 X 18
• BRAKES

  add remove
  • Front Brake Type:
    Hydraulic Disc
  • Rear Brake Type:
    Hydraulic Disc
  • Anti-Lock Brakes:
    Not Available
