Specifications

• ENGINE

  add remove
  • Engine Type:
    Single-Cylinder
  • Cylinders:
    1
  • Engine Stroke:
    4-Stroke
  • Cooling:
    Liquid
  • Valves:
    4
  • Valves Per Cylinder:
    4
  • Valve Configuration:
    DOHC
  • Bore (in):
    3.07
  • Stroke (in):
    2.06
  • Displacement (cc):
    249
  • Compression Ratio:
    14.1:1
  • Carburetion Brand:
    Keihin
  • Carburetor:
    No
  • Carburetion Type:
    Fuel Injected
  • Fuel Requirements:
    Regular
  • Turbocharged:
    No
  • Supercharged:
    No
• TRANSMISSION

  add remove
  • Transmission Type:
    Manual
  • Number Of Speeds:
    5
  • Primary Drive (Rear Wheel):
    Chain
  • Reverse:
    No
• TECHNICAL SPECIFICATIONS

  add remove
  • Length (in):
    85.4
  • Width (in):
    32.3
  • Height (in):
    49.6
  • Wheelbase (in):
    58.3
  • Ground Clearance (in):
    13
  • Dry Weight (lbs):
    230.1
  • Wet Weight (lbs):
    240.2
  • Fuel Capacity (gal):
    1.64
  • Engine Displacement to Weight (cc):
    1.08
• SUSPENSION

  add remove
  • Front Suspension Type:
    Inverted Fork
  • Front Suspension Size (in):
    1.9
  • Front Travel (in):
    12.4
  • Front Adjustable Fork Pre-Load:
    No
  • Front Adjustable Rebound Damping:
    Yes
  • Front Central Suspension Strut:
    No
  • Rear Suspension Brand Name:
    UNI-TRAK®
  • Rear Suspension Type:
    Twin Sided Swing Arm
  • Rear Travel (in):
    12.4
  • Rear Adjustable Shock / Spring Pre-Load:
    Yes
  • Rear Adjustable Rebound Damping:
    Yes
  • Number Rear Shock Absorbers:
    1
  • Rear Suspension Material:
    Aluminum
  • Steering Damper:
    No
  • Air Adjustable:
    No
  • Front Suspension Brand Name:
    KYB
• WHEELS & TIRES

  add remove
  • Tube / Tubeless:
    Tubed
  • Front Tire (Full Spec):
    Dunlop® Geomax AT18F: 80/100-21 51M
  • Rear Tire (Full Spec):
    Dunlop® Geomax AT18 110/100-18 64M
• BRAKES

  add remove
  • Front Brake Type:
    Disc
  • Front Brake Diameter (in):
    10.6
  • Rear Brake Type:
    Disc
  • Rear Brake Diameter (in):
    9.4
• SEATS

  add remove
  • Seat Type:
    One-Piece
  • Seat Location:
    Driver
  • Seat Material:
    Vinyl
  • Seat Height (in):
    37.3
  • Number Of Seats:
    1
