Specifications

• Engine

  add remove
  • Engine Type:
    Parallel Twin
  • Engine:
    Standard
  • Cylinders:
    2
  • Engine Stroke:
    4-Stroke
  • Cooling:
    Liquid
  • Valves:
    8
  • Valves Per Cylinder:
    4
  • Valve Configuration:
    SOHC
  • Bore (mm):
    92
  • Bore (in):
    3.62
  • Stroke (mm):
    75.2
  • Stroke (in):
    2.96
  • Displacement (cc):
    999
  • Displacement (ci):
    60.9
  • Starter:
    Electric
  • Fuel Type:
    Gas
  • Fuel Requirements:
    Regular
  • Carburetion:
    Standard
  • Fuel Injector:
    Yes
  • Fuel Injector Size (mm):
    44
  • Carburetor:
    No
  • Carburetion Type:
    Fuel Injected
  • Parental Controls:
    Not Available
  • Snorkel Air Intake:
    Not Available
  • Engine Block Heater:
    Not Available
  • Speed Governor:
    No
  • Other Engine:
    Not Available
  • Bore And Stroke:
    92.0mm x 75.1mm
  • Compression Ratio:
    10:1
  • Induction:
    Fuel Injection (PGM-FI); 44mm throttle body
  • Valve Train:
    Unicam® SOHC; four valves per cylinder
• Drive Train

  add remove
  • Transmission:
    Six-speed automatic Dual-Clutch Transmission (DCT) with reverse; four drive modesinclude 2WD, 4WD, Turf and Differential lock; paddle shifters with three shift modes(standard, sport, and manual)
  • Driveline:
    Direct front and rear driveshafts
• Chassis Suspension Brakes

  add remove
  • Front Suspension:
    Independent double-wishbone; 10.6-inch travel
  • Rear Suspension:
    Independent double-wishbone; 10.0-inch travel
  • Front Brake:
    Dual 210mm hydraulic discs
  • Rear Brake:
    Dual 210mm hydraulic discs
  • Front Tires:
    27 x 9-14
  • Rear Tires:
    27 x 11-14
• Dimensions

  add remove
  • Length:
    117.1 inches
  • Width:
    63.0 inches
  • Height:
    76.9 inches
  • Wheelbase:
    80.2 inches
  • Bed Capacity:
    1000 pounds for 49- state models; 600 pounds for CA model
  • Ground Clearance:
    13.6 inches
  • Turning Radius:
    1598 pounds - Includes all standard equipment, required fluids and full tank of fuel.
  • Curb Weight:
    1598 pounds - Includes all standard equipment, required fluids and full tank of fuel.
  • Fuel Capacity:
    7.9 gallons, including 1.7-gallon reserve
  • Towing Capacity:
    2500 pounds
• Other

  add remove
  • Safety:
    Recommended for drivers 16 years of age and older.
• Factory Warranty Information

  add remove
  • Optional Extended:
    Extended coverage available with a HondaCare® Protection Plan
• TRANSMISSION

  add remove
  • Transmission:
    Standard
  • Transmission Type:
    Manual / Automatic Clutch
  • Number Of Speeds:
    6
  • Hi / Low Range:
    Yes
  • Primary Drive (Rear Wheel):
    Shaft
  • Primary Drive (Front Wheel):
    Shaft
  • Reverse:
    Yes
  • Adjustable Throttle:
    Not Available
  • Other Transmission:
    Not Available
• DRIVE LINE

  add remove
  • Driveline:
    Standard
  • Driveline Type:
    Selectable 4X2 / 4X4
  • Number Of Driveline Modes:
    4
  • Rear Solid Axle:
    No
  • Limited Slip Differential:
    Not Available
  • Differential Lock:
    Standard
  • Differential Lock Location:
    Front / Rear
  • Other Drive Line:
    Not Available
• TECHNICAL SPECIFICATIONS

  add remove
  • Dimensions:
    Standard
  • Length (mm):
    2974.3
  • Width (in):
    63
  • Width (mm):
    1600.2
  • Height (in):
    76.9
  • Height (mm):
    1953.3
  • Wheelbase (in):
    80.2
  • Wheelbase (mm):
    2037.1
  • Turning Radius (ft):
    13.8
  • Ground Clearance (in):
    13.6
  • Ground Clearance (mm):
    345.4
  • Weight:
    Standard
  • Towing Capacity (lbs):
    2500
  • Towing Capacity (kgs):
    1134
  • Capacities:
    Standard
  • Fuel Capacity (gal):
    7.9
  • Fuel Capacity (l):
    29.9
  • Fuel Capacity Reserve (gal):
    1.7
  • Fuel Capacity Reserve (l):
    6.4
  • Performance:
    Standard
  • Payload Capacity (lbs):
    1000
  • Payload Capacity (kgs):
    453.6
  • Wet Weight (lbs):
    1598
  • Wet Weight (kg):
    724.9
• SUSPENSION

  add remove
  • Front Suspension:
    Standard
  • Front Suspension Type:
    Independent Double Wishbone
  • Front Travel (in):
    10.6
  • Front Travel (mm):
    268
  • Rear Suspension:
    Standard
  • Rear Suspension Type:
    Independent Double Wishbone
  • Rear Suspension Material:
    Steel
  • Rear Travel (in):
    10
  • Rear Travel (mm):
    254
  • Number Rear Shock Absorbers:
    2
  • Rear Stabilizer Bar:
    Yes
  • Air Adjustable:
    No
  • Center Suspension:
    Not Available
  • Front Adjustable Fork Pre-Load:
    Yes
  • Rear Adjustable Shock / Spring Pre-Load:
    Yes
  • Other Suspension:
    Optional
• WHEELS & TIRES

  add remove
  • Wheels:
    Standard
  • Wheels Composition:
    Aluminum
  • Front Tire Diameter (in):
    27
  • Rear Tire Diameter (in):
    27
  • Wheel Weights:
    Not Available
  • Tires:
    Standard
  • Front Tire Width:
    9
  • Front Wheel Diameter:
    14
  • Rear Tire Width:
    11
  • Rear Wheel Diameter:
    14
  • Front Tire (Full Spec):
    Armstrong Dirt Master 2.0: 27 x 9-14
  • Rear Tire (Full Spec):
    Armstrong Dirt Master 2.0: 27 x 11-14
  • Tire Chains:
    Not Available
  • Spare Tire:
    Not Available
  • Tire Brand:
    Armstrong
  • Other Wheels & Tires:
    Not Available
• BRAKES

  add remove
  • Brakes:
    Standard
  • Front Brake Type:
    Hydraulic Disc
  • Front Brake Diameter (in):
    8.3
  • Front Brake Diameter (mm):
    210
  • Rear Brake Type:
    Hydraulic Disc
  • Rear Brake Diameter (in):
    8.3
  • Rear Brake Diameter (mm):
    210
  • Anti-Lock Brakes:
    Not Available
  • Parking Brake:
    Standard
  • Engine Braking:
    Standard
  • Regenerative Braking:
    Not Available
  • Regenerative Deceleration:
    Not Available
  • Linked Brake System Front to Rear:
    Not Available
  • Other Brakes:
    Not Available
